500v phab ntsa-mounted nquag harmonic lim
Nrhiav Ob txhais tes zoo tshaj plaws los txhim kho lub zog zoo? Peb 500v phab ntsa-mounted nquag ua haujlwm haronic lim muaj kev tiv thaiv zoo thiab kev tiv thaiv zoo. Tshawb nrhiav li cas Geya txoj kev daws teeb meem tshiab tuaj yeem ua tau raws li koj cov kev xav tau. Tiv tauj peb kom paub cov ntaub ntawv ntau ntxiv!
Lub 500v phab ntsa-mounted nquag harmonic lim (ahf) muab cov kev tsim txom zoo rau peb-theem plaub-hlau (3p4W) 500v lub zog hluav taws xob (3p4W) 500v lub zog hluav taws xob (3p4W) 500v lub zog hluav taws xob (3p4w) 500v lub zog hluav taws xob (3p4w) 500v lub zog hluav taws xob (3p4w) 500v lub zog hluav taws xob (3p4w) 500v lub zog hluav taws xob (3p4w) 500v lub zog hluav taws xob (3p4w) 500v lub zog hluav taws xob (3p4w) 500v lub zog hluav taws xob (3p4w) 500v lub zog fais fab. Siv DSP + CPLD digital tswj tub ntxhais thiab peb-theem topology, no ahf muab cov txiaj ntsig tam sim no. Nws cov qauv tsim qauv tso cai rau cov kev daws teeb meem los ntawm kev sib txuas tau sib txuas sib txuas, ua kom yooj yim txhim kho thiab saib xyuas. Lub lim dej 500v-mounted AHF zoo lim ua kom zoo nkauj los ntawm thib 2 txog 50 qhov kev txiav txim, ua tiav ib tus nqi lim txog li 95%. Nyob rau 100A, no phab ntsa-mounted chav tsev ua kom ntseeg tau kev txhim khu kev qha zoo hauv high-voltage muaj cov ntawv thov.
Cov Qauv Qhia Ntawv:
| Gy | AHF | 0.4 | 50A | / | 4L | W |
| Tus Code | Nquag harmonic lim | Voltage theem 0.5: 500v ± 20% |
Kev ntsuas kev muaj peev xwm (KvAR) 100A | 3L: Peb-theem peb-xaim 4L: Peb-theem plaub-xaim |
W: Phab ntsa-mounted |
Nta:
● Siv DSP
● Txais yuav cov qauv tsim qauv, uas pab txhawb kev sib txuas ntawm ntau yam kev sib txuas, yuav siv sijhawm me me thiab yog yooj yim tswj.
● Cov qauv tsim qauv ntawm cov huab cua ywj pheej thiab cov ntaub ntawv ywj siab ua kom muaj kev lag luam ruaj khov ntawm cov khoom siv.
● Nws tuaj yeem lim cov kev sib haum xeeb ntau qhov kev sib haum xeeb, txij li 2 txog 50 qhov teeb meem, thiab daws qhov teeb meem ntawm peb-theem tsis muaj peb-theem unbalance tib lub sijhawm.
Tus nqi harmonic harmonic muaj siab. Yog tias lub peev xwm tso cai, cov harmonic txheej txheej tam sim no siv tau li siab li 95%. Teeb 100% txwv cov zis tam sim no kom ntseeg tau tias ntev kev ua haujlwm ntev ntawm cov khoom siv.
Cov Ntawv Thov:
500v phab ntsa-mounted nquag ua hauj lwm harmonic lim yog qhov tseem ceeb rau kev tswj hwm lub zog zoo hauv ntau-voltage muaj chaw:
● Hnyav Kev Lag Luam:Tiv thaiv cov khoom siv rhiab thiab ua kom muaj kev tswj hwm txhim khu kev qha ntawm high-zog machinery hauv kev lag luam zoo li tsuas, roj thiab kev tsim khoom.
● Txuas txuas ntxiv hluav taws xob:Smoothing zog hloov pauv thiab hangonic distortions qhia los ntawm cov hluav taws xob txuas ntxiv xws li lub hnub ci tshiab thiab cua.
● High-voltage cov chaw zov me nyuam:Muab lub zog huv rau qhov tseem ceeb nws cov cuab yeej tsim hauv cov ntaub ntawv kev ua haujlwm ntawm 500v.
● Muaj lub cev muaj zog tsav:Txo cov neeg tsis sib haum xeeb uas tau tsim los ntawm cov tsav tsheb loj, txhim kho cov nqi zog thiab txo lub zog loj.
500v phab ntsa-mounted nquag ua hauj lwm harters harters harters ua rau muaj kev daws teeb meem zoo rau kev xav tau zoo ntawm cov kev siv voltage high-voltage siab.
Kev Ntsuas Cov Qauv:
| 220V Series | 380V Series | 500V Series 500V | 690V Series | ||
| Qho siab | <2000m, saum 2000m, derate raws li GB / T3859.2 | ||||
| Thaj kub cua sov | -20 ~ + 50 ℃ | ||||
| Tus txheeb ze cov av noo | I≤90%, tsis muaj hws rau saum npoo thaum lub hlis tsawg kawg yog 25 ℃ | ||||
| Kev Nyab Xeeb Qib | Qib III hauv qab no | ||||
| Kev Lag Luam Hluav Taws Xob | AC220V ± 20% | AC380V က ac 20 20 20 20 20 20% | AC500V ±00V ± 20% | AC690V ± 20% | |
| Ua haujlwm zaus | 50Hz ± 5% | ||||
| Nyiaj Them Tam Sim No | 25a | 25/505/100 / 150A | 100A | 100A | |
| Daim phiaj qauv | L / n | 35W / 3P4W | 35W / 3P4W | 35W / 3P4W | |
| Cov naj npawb ntawm cov koog Txuas nyob rau hauv parallel | Roj teeb | ||||
| Zuag qhia tag nrho cov tshuab efficiency | ≥97% | ||||
| Daim phiaj qauv | 32KHZ | 16kHz | 12.8KHz | 12.8KHz | |
| Kev Them Nyiaj Ntau | 2 ~ 50times, tus nqi them ib zaug yog kho tau | ||||
| Kev Xaiv Ua Haujlwm | Refiorive zog | Reflective zog, reactive fais + asymmetry | |||
| Refiorive zog Them Nqi | ≥9% | > 92% | |||
| Nruab nrab lim kev txawj | Nruab nrab kab lim cov peev xwm yog 3 zaug uas ntawm theem lim muaj peev xwm | ||||
| Sijhawm Sijhawm Teb | <10ms | 150 | 150 | 150 | |
| Suab nrov | ≤60DB | ≤60DB | I≤65DB | I≤65DB | |
| Txoj Kev Tswj Xyuas | 2-txoj kev RS485 interface (txhawb nqa GPRS / Wifi) | ||||
| Kev povhwm | Tshaj dhau, software / Khoom siv overvurrent, daim phiaj overvoltage thiab undervoltage, lub zog tsis ua hauj lwm, kev tiv thaiv, zaus kev tawm tsam kev tiv thaiv, thiab lwm yam. | Overload, software / kho vajtse overvurrent, grid overvoltage thiab undervoltage tsis txaus, kev ua tsis tiav, zaus kev tiv thaiv kab ke, thiab lwm yam. | |||
| Txoj kev teeb tsa | Khib / phab ntsa-mounted | Khib | |||
| Tuaj Tuaj Kab | Rov qab los (rack hom), sab saud (phab ntsa-mounted) | Rov qab cov kab | |||
| Kev Tiv Thaiv Qib | Liphaus20 | ||||
Qauv & Specification:
| Qauv | ||||
|---|---|---|---|---|
| Tus Qauv Qauv | Rated tam sim no (a) | System Voltage (V) | Qhov loj me (D * W * H) | Cua txias txoj kev |
| GY APF-0.22-25A / 2L-R / W | 25 | 220 | 220 * 330 * 160 hli | Yuam Kev Cua Txias |
| Gy apf-0.4-25A / 4L-R / W | 25 | 380 ± 20% | 460 * 490 * 89mm | |
| Gy apf-0.4-5050 / 4L-r / w | 50 | 380 ± 20% | 460 * 490 * 89mm | |
| GY APF-0.4-75A / 4L-R / W | 75 | 380 ± 20% | 500 * 510 * 190 hli | |
| GY APF-0.4-100A / 4L-R / W | 100 | 380 ± 20% | 500 * 550 * 240mm | |
| Gy apf-0.4-150a / 4L-r / w | 150 | 380 ± 20% | 500 * 550 * 240mm | |
| Gy apf-0.5-100a / 4L-R / W | 100 | 500 ± 20% | 495 * 675 * 275 hli | |
| Gy apf-0.69-100a / 4L-R / W | 100 | 690 ± 20% | 495 * 675 * 275 hli | |
