Khoom
Geya Phab Ntsa Cov Phab Ntsa Cov Khoom Siv-Wll005B1-5.22kWhwh
Geya Phab Ntsa Cov Phab Ntsa Cov Khoom Siv-Wll005B1-5.22kW-Mounted phab ntsa cia kev daws teeb meem rau kev siv nyob. Nrog 5.22kWwH tag nrho lub peev xwm thiab 4.96KT siv zog, cov nqi hluav taws xob txhim khu kev qha, thiab txhawb nqa hluav taws xob rov qab - thaum tab tom ua haujlwm rau hauv koj lub tsev ib puag ncig.
Cov Nta Tseem Ceeb & Cov Txiaj Ntsig Ntawm Geya Phab Ntsa-Mounted Thaj Chaw Nyob-Wll005B1-5.22kWhwh
Muaj Peev Xwm Loj & Kev Ua Haujlwm
5.22kWh tag nrho lub zog | 4.96KWHTHAB UAS SIV LUB ZOG (DC)
95% Max. Qhov tob ntawm tso tawm (dod): siv yuav luag txhua lub zog khaws cia yam tsis muaj roj teeb lub neej.
● Ultra-txhim khu kev qha & tu-dawb
Lub Txheej Txheem Ntuj Txias: Tsis muaj tus kiv cua nrov lossis ua kom muaj cua txias.
Kev Ua Haujlwm Thoob Plaws: Ua haujlwm flawlessly hauv qhov kub ntawm 0 ° C rau 55 ° C.
Kev tiv thaiv muaj zog: kev tiv thaiv tawm tsam ntau dua tam sim no, tshaj-voltage, luv luv hluav taws xob, thiab huab cua sov.
Chaw Chaw-txuag & hloov tau
Kev Tsim Kho Cov: Slim Qhov Ntev (632x418x136.5mm) thiab 45kg Nyhav Rau Yooj Yim Phab Ntsa-Mounting lossis pem teb-sawv.
IP20 Ntsuam Xyuas: Zoo tagnrho rau Kev Siv Sab Hauv Tsev Siv Hauv Chaw Nyob Hauv Chaw Nyob Hauv Chaw Nyob Hauv Chaw Nres Tsheb, Hauv Paus Khaub Ncaws, lossis Chav Dej hluav taws xob.
● Kev Nyab Xeeb Kev Nyab Xeeb & Ntev
RoHS raws cai: cov ntaub ntawv zoo ib puag ncig.
5-xyoo lav: Thaub los ntawm Geya txoj kev ntseeg siab.
CE, UN38.3, MSDS tau pov thawj: ntsib cov qauv kev nyab xeeb thoob ntiaj teb.
Vim li cas thiaj xaiv Geya Ess-Wll005B1?
● Kev tswj hwm lub zog zoo: khi kev sib xyaw nrog cov khoom plig ci ntsa iab lossis cov phiaj xwm kom muaj zog thiab txo qis ntawm lub ncov tails.
● Tom ntej-npaj ruaj khov: Expand muaj peev xwm los txuas ntau yam (nce txog 6p).
Kev ua haujlwm nyob ntsiag to: zoo meej rau cov suab nrov-rhiab ib puag ncig.
Kev Ua Tshwj Xeeb
| Tus qauv | MowerCool-Wll005B1 |
| Tag Nrho Lub Zog | 5.22kWh |
| Siv Zog (DC) | 4.96KWHWH |
| Fai fab hov ntau | 44.8 ~ 57.6VDC |
| Nominal voltage | 5.12vdc |
| Kev Muaj Peev Xwm | 102H |
| Max. Them nqi voltage | 57.6VDC |
| Nominal rho tawm tam sim no | 50A (1p) / 100A (2P) / 150A (3P) / 160A (4P) / 160A (5P) / 160A (6P) |
| Nominal them tam sim no | 50A (1p) / 100A (2P) / 150A (3P) / 160A (4P) / 160A (5P) / 160A (6P) |
| Qho hnyav | 45Kg |
| Dimension (hli) (h * l) | 632 * 418 * 136.5mm |
| Max.Recommed Dod | 95% |
| Kev khiav hauj lwm mob | Nyob Sab Hauv Tsev |
| Kev khiav hauj lwm them | 0 ~ 55 ° C |
| Kub tawm | 0 ~ 55 ° C |
| Qauv Ambient Kub Ntau | 0 ~ 40 ° C |
| Cia kub ntau yam | > 1 hlis 0 ~ 35 ° C / A≤1 hli ~ 45 ° C |
| Kev vaum | 5% ~ 95% (rh) (tsis muaj hws) |
| Hla kev voltage qeb | ' |
| Cua Txias Hom | Ntuj Txias |
| Rooj plaub | Hlau |
| Kev muab cia | Phab ntsa-mouted lossis pem teb-sawv |
| IP kev ntsuam xyuas | IP 20 |
| Chav Tiv Thaiv | I |
| Max. Sib Txuas Naj | 6p |
| Kev sib txuas lus | Tuaj yeem / rs485 |
| Kev tiv thaiv roj teeb | Dhau-tam sim no / tshaj-voltage / luv Circuit Court / Under-voltage / dhau-kub |
| Ntawv pov thawj | CE, UN38.3, MSDS |
| Kev lav | 5 xyoo |
